- ADJUSTABLE & REVERSIBLE - 12 STAGES
- 6 STAGES OF DROP - 80MM/110MM/130MM/140MM/160MM/190MM
- 6 STAGES OF RISE - 50MM/80MM/105MM/110MM/135MM/165MM
- 10MM DUAL SUPPORT GUSSETS FOR ADDED STRENGTH
- NEW MODEL WITH 3 PIN HOLES (RANGER SHORT SHANK COMPATIBLE)
- USES 12.9 GRADE HIGH TENSILE 16MM BOLTS
- 25MM X 75MM HEAVY DUTY BALL PLATFORM.
- MATT BLACK SEAGUARD FINISH
- ROBOTIC WELDED FOR CONSISTENT QUALITY
- CNC MACHINED FOR MAXIMUM ACCURACY
- FITS 2" X 2" TOWBAR RECEIVERS
GROSS TRAILER WEIGHT: 4000KG
TONGUE WEIGHT: 400KG
BALL HOLE SIZE: 7/8"
MAX DROP: 190MM
MAX RISE: 165MM
LENGTHS: (MEASURED FROM CENTRE OF PIN HOLE TO CENTRE OF BALL HOLE)
266MM LENGTH
PIN HOLE TO END OF SHANK 115MM
305MM LENGTH
PIN HOLE TO END OF SHANK 76MM
331MM LENGTH
PIN HOLE TO END OF SHANK 50MM (SUITS FORD RANGER)
